Specification
Model NEO α (Alpha)
Display 5-inch OLED HD touch screen
Chassis Aviation aluminum alloy
CPU Realtek RTD1619DR ARM Cortex-A55(hexa-core)
GPU ARM Mali-G51 MP3
DAC ESS 9038Pro
Audio Processor XMOS XU216
Internal SSD 512G SSD (M.2 SATA 3.0 2280 interface protocol, up to 1TB)
SATA Internal SATA3.0 HDD bay*1 (support 2.5/3.5 inch HDD，hard drives are not included)
Wi-Fi 2.4G+5G dual band WiFi, 802.11 a/b/g/n/AC 2T2R MIMO 867Mbps
Ethernet RJ-45(10/100/1000Mbps)
HDMI Main Output HDMI 2.0a support 4K@60fps/12Bit/HDR/BT2020/YCbCr 4:4:4 video ouput
Support audio passthrough
HDMI DSD Audio Output HDMI 1.4
Music: support DSD 64 2CH/5.1CH(DSD Native)
Movie: support audio passthrough
Video Decoding 4K@60p HEVC/H.265 12Bit HDR10, HDR10+, Dolby Vision
Audio Decoding Support true-hd HD audio passthrough, stereo PCM decoding
DAC Audio Decoding Support up to stereo DSD512, PCM 768KHz 32Bit, MQA
Bluetooth Audio Input Qualcomm QCC5125 bluetooth module(BT5.0)
Support audio protocols such as SBC/AAC/aptX/aptX LL/aptX HD/LDAC
USB Audio Input USB Audio compatible system: Windows（7，10）、Mac、Android、iOS
Support up to stereo DSD512, PCM 768KHz 32Bit, MQA
Digital Audio Input USB DAC input, Coaxial input, Optical input, Bluetooth audio input
Digital Audio Output Optical output, HDMI output, USB Audio output, Bluetooth audio output
Analog Audio Output Preamplifier output: XLR(balanced), RCA
Headphone amplifier output: 6.35mm single end
USB USB3.0*2，USB2.0*2
Control Methods Remote control, Mobile APP control, Touch screen control, TCP/IP control（WOL), RS232 serial port control, IR IN interface control
Headphone Impedance 16-300Ω (loe-gain mode: 16-32Ω/high-gain mode: 32-300Ω)
XLR(balanced) Output Output Level(Vrms): 4.3 Vrms
THD+N: -115dB（0.000167%@1kHz）
Noise: less than 2uVrms
SNR: 127dB@1kHz
frequency response: ±0.25dB(20Hz-20kHz)
CROSSTALK: -130dB@1kHz
DNR: 127dB@1kHz
RCA(single-ended) Output Output Level(Vrms): 2.1 Vrms
THD+N: -114dB(0.000185%@1kHz)
Noise: less than 2uVrms
SNR: 124dB@1kHz
frequency response: ±0.25dB(20Hz-20kHz)
CROSSTALK: -126dB@1kHz
DNR: 125dB@1kHz
Headphone 6.35mm Single-Ended Output(low-gain mode) Output Level(Vrms): 1.1 Vrms
THD+N: -109dB(0.00035%@1kHz)
Noise: less than 2uVrms
SNR: 123dB@1kHz
frequency response: ±0.25dB(20Hz-20kHz)
CROSSTALK: -123dB@1kHz
DNR: 123dB@1kHz
Max Power: 76mW(16Ω)/38mW(32Ω)
Headphone 6.35mm Single-Ended Output(high-gain mode) Output Level(Vrms): 3.4 Vrms
THD+N: -111dB(0.00035%@1kHz)
Noise: less than 2uVrms
SNR: 124dB@1kHz
frequency response: ±0.25dB(20Hz-20kHz)
CROSSTALK: -123dB@1kHz
DNR: 124dB@1kHz
Max Power: 361mW(32Ω)/39mW(300Ω)
Power Supply AC 110~240V 50/60Hz
Dimensions 430mm(W)*300mm(D)*105mm(H)
Packing List Remote control*1, Power cable*1, Hard drive fixing screws*4, Screwdriver*1, User Manual*1
